Automate Your Deployments with Kamal 2 and GitHub Actions

#devops #development #rails #automation

Deployments shouldn’t be complex. You don’t need a lot of complicated configurations. That’s where Kamal 2 helps. It makes setting up servers and deploying easy.

We’ll use Kamal 2 to set up auto-deployments from GitHub Actions.

GitHub and Kamal Icons: A simple, clean image with GitHub, Kamal, and Ruby logos connected in some way, perhaps with gears or arrows, to symbolize the integration of these technologies in an automated workflow

Here are step-by-step instructions to set up Kamal and create an auto-deploy process #

1. Start by adding Kamal to your Gemfile

group :tools do
  gem “kamal”, “~> 2”
end

2. Install and generate binstub for Kamal:

bundle install && bundle binstub kamal

3. Update config/deploy.yml with your server details and setup caching:

# Configure builder setup.
builder:
  arch: amd64
  cache:
    type: gha
    options: mode=max
    image: app-build-cache
  secrets:
    - RAILS_MASTER_KEY # if your build depends on credentials

4. Set up secrets in .kamal/secrets

KAMAL_REGISTRY_USERNAME=$KAMAL_REGISTRY_USERNAME
KAMAL_REGISTRY_PASSWORD=$KAMAL_REGISTRY_PASSWORD
RAILS_MASTER_KEY=$RAILS_MASTER_KEY

5. Create a new GitHub Actions workflow to run the deployment with Kamal using .github/workflows/release.yml

name: Release

on:
  workflow_dispatch:
  push:
    branches:
      - main

concurrency:
  group: ${{ github.workflow }}-${{ github.event.pull_request.number || github.ref }}
  cancel-in-progress: false # Prevents ongoing deployments from being canceled

env:
  SERVER_ADDR: “HERE IS YOUR PRODUCTION SERVER ADDR”

jobs:
  deploy:
    runs-on: ubuntu-latest

    permissions:
      contents: read
      packages: write
      attestations: write
      id-token: write

    env:
      DOCKER_BUILDKIT: 1
      RAILS_ENV: production
      BUNDLE_WITHOUT: “default development test production profiling”
      BUNDLE_WITH: tools

    steps:
      - name: Checkout code
        uses: actions/checkout@v4

      - name: Set up Ruby
        uses: ruby/setup-ruby@v1
        with:
          ruby-version: 3.3.0
          bundler-cache: true
          cache-version: "tools-v1-${{ runner.os }}"

      - name: Set up Docker Buildx for cache
        uses: docker/setup-buildx-action@v3

      - name: Expose GitHub Runtime for cache
        uses: crazy-max/ghaction-github-runtime@v3

      - name: Set up SSH connection
        run: |
          # Create SSH directory and write the private key
          mkdir -p ~/.ssh && echo "$SSH_PRIVATE_KEY" > ~/.ssh/id_rsa && chmod 600 ~/.ssh/id_rsa
          # Enable current SSH key
          eval $(ssh-agent -s) && ssh-add ~/.ssh/id_rsa
          # Add the server to known_hosts (use `-p 2222` for custom port if needed)
          ssh-keyscan $SERVER_ADDR >> ~/.ssh/known_hosts
        env:
          SSH_PRIVATE_KEY: ${{ secrets.SSH_PRIVATE_KEY }}

      - name: Deploy with Kamal
        run: bin/kamal deploy
        env:
          RAILS_MASTER_KEY: ${{ secrets.RAILS_PRODUCTION_MASTER_KEY }}
          KAMAL_REGISTRY_PASSWORD: ${{ secrets.GITHUB_TOKEN }}
          KAMAL_REGISTRY_USERNAME: ${{ github.actor }}

6. Provide secrets on GitHub Settings -> Secrets and variables:

All secrets need to be added to the GitHub Actions secrets manager. You need to provide SSH_PRIVATE_KEY and RAILS_PRODUCTION_MASTER_KEY. Here’s GitHub’s guide on how to add them .

Let me explain what each part does and why it’s needed. #


name: Release

on:
  workflow_dispatch:
  push:
    branches:
      - main

This part sets up our GitHub Action to run. We use workflow_dispatch for manual deployments and push to the main branch for automatic deployments when changes are made.

concurrency:
  group: ${{ github.workflow }}-${{ github.event.pull_request.number || github.ref }}
  cancel-in-progress: false # We don’t want to cancel ongoing deployments

concurrency makes sure that deployments don’t overlap. The group is set dynamically, and we don’t cancel in-progress deployments to avoid issues from partial releases.

jobs:
  deploy:
    runs-on: ubuntu-latest

    permissions:
      contents: read
      packages: write
      attestations: write
      id-token: write

The deploy job runs on an Ubuntu machine. The permissions allow it to interact with the package registry and use the ID token for authentication.

    env:
      DOCKER_BUILDKIT: 1
      RAILS_ENV: production
      BUNDLE_WITHOUT: “default development test production profiling”
      BUNDLE_WITH: tools

The environment variables do a few things. They enable Docker BuildKit, set the Rails environment to production, and control which dependencies to include or exclude during bundling.

    steps:
      - name: Checkout code
        uses: actions/checkout@v4

The first step is to check out your code. This is necessary to access your application files.

      - name: Set up Ruby
        uses: ruby/setup-ruby@v1
        with:
          ruby-version: 3.3.0
          bundler-cache: true
          cache-version: "tools-v1-${{ runner.os }}"

Next, we set up Ruby. We use version 3.3.0, and bundler caching helps speed up future runs by saving installed gems.

      - name: Set up Docker Buildx for cache
        uses: docker/setup-buildx-action@v3

We use Docker Buildx to handle advanced builds, including caching, and keep things efficient.

      - name: Expose GitHub Runtime for cache
        uses: crazy-max/ghaction-github-runtime@v3

This step is for caching. It helps Docker use the GitHub runner’s internal state to speed up builds.

      - name: Setup SSH connection
        run: |
          # Create SSH directory and write the private key
          mkdir -p ~/.ssh && echo "$SSH_PRIVATE_KEY" > ~/.ssh/id_rsa && chmod 600 ~/.ssh/id_rsa
          # Enable current SSH key
          eval $(ssh-agent -s) && ssh-add ~/.ssh/id_rsa
          # Add the server to known_hosts
          ssh-keyscan SERVER_IP_ADDRs >> ~/.ssh/known_hosts
        env:
          SSH_PRIVATE_KEY: ${{ secrets.SSH_PRIVATE_KEY }}

This step sets up SSH. It creates the SSH directory, adds the private key, and sets the correct permissions. We start ssh-agent to manage the keys and add our server to known_hosts to prevent prompts during deployment.

      - run: bin/kamal deploy
        env:
          RAILS_MASTER_KEY: ${{ secrets.RAILS_PRODUCTION_MASTER_KEY }}
          KAMAL_REGISTRY_PASSWORD: ${{ secrets.GITHUB_TOKEN }}
          KAMAL_REGISTRY_USERNAME: ${{ github.actor }}

Finally, we run the Kamal deploy command. The RAILS_MASTER_KEY is used to decrypt credentials, and we authenticate with the Docker registry using GitHub secrets for username and password.

Next, let’s look at the deploy configuration file at config/deploy.yml: #

# Configure builder setup.
builder:
  arch: amd64
  cache:
    type: gha
    options: mode=max
    image: app-build-cache
  secrets:
    - RAILS_MASTER_KEY

This configuration helps Kamal manage the build process. It sets the architecture (amd64), uses GitHub Actions for caching, and stores secrets like RAILS_MASTER_KEY securely.

That’s it! This setup gives you an easy, repeatable deployment process using Kamal 2 and GitHub Actions.

If you follow along and set this up, you’ll save time on deployments. Let me know if you have issues or want to customize this further. I’d love to hear about your experience with Kamal.
