Automate Your Deployments with Kamal 2 and GitHub Actions
Deployments shouldn’t be complex. You don’t need a lot of complicated configurations. That’s where Kamal 2 helps. It makes setting up servers and deploying easy.
We’ll use Kamal 2 to set up auto-deployments from GitHub Actions.
Here are step-by-step instructions to set up Kamal and create an auto-deploy process #
1. Start by adding Kamal to your Gemfile
group :tools do
gem “kamal”, “~> 2”
end
2. Install and generate binstub for Kamal:
bundle install && bundle binstub kamal
3. Update config/deploy.yml
with your server details and setup caching:
# Configure builder setup.
builder:
arch: amd64
cache:
type: gha
options: mode=max
image: app-build-cache
secrets:
- RAILS_MASTER_KEY # if your build depends on credentials
4. Set up secrets in .kamal/secrets
KAMAL_REGISTRY_USERNAME=$KAMAL_REGISTRY_USERNAME
KAMAL_REGISTRY_PASSWORD=$KAMAL_REGISTRY_PASSWORD
RAILS_MASTER_KEY=$RAILS_MASTER_KEY
5. Create a new GitHub Actions workflow to run the deployment with Kamal using .github/workflows/release.yml
name: Release
on:
workflow_dispatch:
push:
branches:
- main
concurrency:
group: ${{ github.workflow }}-${{ github.event.pull_request.number || github.ref }}
cancel-in-progress: false # Prevents ongoing deployments from being canceled
env:
SERVER_ADDR: “HERE IS YOUR PRODUCTION SERVER ADDR”
jobs:
deploy:
runs-on: ubuntu-latest
permissions:
contents: read
packages: write
attestations: write
id-token: write
env:
DOCKER_BUILDKIT: 1
RAILS_ENV: production
BUNDLE_WITHOUT: “default development test production profiling”
BUNDLE_WITH: tools
steps:
- name: Checkout code
uses: actions/checkout@v4
- name: Set up Ruby
uses: ruby/setup-ruby@v1
with:
ruby-version: 3.3.0
bundler-cache: true
cache-version: "tools-v1-${{ runner.os }}"
- name: Set up Docker Buildx for cache
uses: docker/setup-buildx-action@v3
- name: Expose GitHub Runtime for cache
uses: crazy-max/ghaction-github-runtime@v3
- name: Set up SSH connection
run: |
# Create SSH directory and write the private key
mkdir -p ~/.ssh && echo "$SSH_PRIVATE_KEY" > ~/.ssh/id_rsa && chmod 600 ~/.ssh/id_rsa
# Enable current SSH key
eval $(ssh-agent -s) && ssh-add ~/.ssh/id_rsa
# Add the server to known_hosts (use `-p 2222` for custom port if needed)
ssh-keyscan $SERVER_ADDR >> ~/.ssh/known_hosts
env:
SSH_PRIVATE_KEY: ${{ secrets.SSH_PRIVATE_KEY }}
- name: Deploy with Kamal
run: bin/kamal deploy
env:
RAILS_MASTER_KEY: ${{ secrets.RAILS_PRODUCTION_MASTER_KEY }}
KAMAL_REGISTRY_PASSWORD: ${{ secrets.GITHUB_TOKEN }}
KAMAL_REGISTRY_USERNAME: ${{ github.actor }}
6. Provide secrets on GitHub Settings -> Secrets and variables:
All secrets need to be added to the GitHub Actions secrets manager. You need to provide SSH_PRIVATE_KEY
and RAILS_PRODUCTION_MASTER_KEY
. Here’s GitHub’s guide on how to add them
.
Let me explain what each part does and why it’s needed. #
name: Release
on:
workflow_dispatch:
push:
branches:
- main
This part sets up our GitHub Action to run. We use workflow_dispatch
for manual deployments and push
to the main
branch for automatic deployments when changes are made.
concurrency:
group: ${{ github.workflow }}-${{ github.event.pull_request.number || github.ref }}
cancel-in-progress: false # We don’t want to cancel ongoing deployments
concurrency
makes sure that deployments don’t overlap. The group is set dynamically, and we don’t cancel in-progress deployments to avoid issues from partial releases.
jobs:
deploy:
runs-on: ubuntu-latest
permissions:
contents: read
packages: write
attestations: write
id-token: write
The deploy
job runs on an Ubuntu machine. The permissions allow it to interact with the package registry and use the ID token for authentication.
env:
DOCKER_BUILDKIT: 1
RAILS_ENV: production
BUNDLE_WITHOUT: “default development test production profiling”
BUNDLE_WITH: tools
The environment variables do a few things. They enable Docker BuildKit, set the Rails environment to production
, and control which dependencies to include or exclude during bundling.
steps:
- name: Checkout code
uses: actions/checkout@v4
The first step is to check out your code. This is necessary to access your application files.
- name: Set up Ruby
uses: ruby/setup-ruby@v1
with:
ruby-version: 3.3.0
bundler-cache: true
cache-version: "tools-v1-${{ runner.os }}"
Next, we set up Ruby. We use version 3.3.0, and bundler caching helps speed up future runs by saving installed gems.
- name: Set up Docker Buildx for cache
uses: docker/setup-buildx-action@v3
We use Docker Buildx to handle advanced builds, including caching, and keep things efficient.
- name: Expose GitHub Runtime for cache
uses: crazy-max/ghaction-github-runtime@v3
This step is for caching. It helps Docker use the GitHub runner’s internal state to speed up builds.
- name: Setup SSH connection
run: |
# Create SSH directory and write the private key
mkdir -p ~/.ssh && echo "$SSH_PRIVATE_KEY" > ~/.ssh/id_rsa && chmod 600 ~/.ssh/id_rsa
# Enable current SSH key
eval $(ssh-agent -s) && ssh-add ~/.ssh/id_rsa
# Add the server to known_hosts
ssh-keyscan SERVER_IP_ADDRs >> ~/.ssh/known_hosts
env:
SSH_PRIVATE_KEY: ${{ secrets.SSH_PRIVATE_KEY }}
This step sets up SSH. It creates the SSH directory, adds the private key, and sets the correct permissions. We start ssh-agent
to manage the keys and add our server to known_hosts
to prevent prompts during deployment.
- run: bin/kamal deploy
env:
RAILS_MASTER_KEY: ${{ secrets.RAILS_PRODUCTION_MASTER_KEY }}
KAMAL_REGISTRY_PASSWORD: ${{ secrets.GITHUB_TOKEN }}
KAMAL_REGISTRY_USERNAME: ${{ github.actor }}
Finally, we run the Kamal deploy command. The RAILS_MASTER_KEY
is used to decrypt credentials, and we authenticate with the Docker registry using GitHub secrets for username and password.
Next, let’s look at the deploy configuration file at config/deploy.yml
: #
# Configure builder setup.
builder:
arch: amd64
cache:
type: gha
options: mode=max
image: app-build-cache
secrets:
- RAILS_MASTER_KEY
This configuration helps Kamal manage the build process. It sets the architecture (amd64
), uses GitHub Actions for caching, and stores secrets like RAILS_MASTER_KEY
securely.
That’s it! This setup gives you an easy, repeatable deployment process using Kamal 2 and GitHub Actions.
